Qty Required
|
Quantity per Parent
If set to 0 the line is skipped during processing.
|
UOM
|
Unit of Measure - Note: must be the stock UOM from the item main
|
Item no
|
Item No in Item Main
|
Description (property key)
|
Item Description if different then the item master
|
Calculated weight
|
Weight if different then the item main
|
Weight UOM
|
Weight Unit of Measure
|
Levels
|
1= Parent, 2 = Child, 3 = child of child etc
|
Calculated Cost
|
Cost if different then the item main
|
Cost UOM
|
Cost Unit of Measure can be different than stock UOM if required
|
Cell Codes
|
Upon configuring and item if the BOM has a valid cell specified in this column the cell will be imported into the system.
View the imported cell in Item Editor by editing component and clicking the Additional Info tab.
|
Comments
|
Comments can be used on custom reports
|
Qty To Cost
|
Qty associated with cost unit of measure
|
WO comments
|
Comments can be used on custom reports
|
PO comments
|
Comments can be used on custom reports like work order or PO
|
Item Error
|
Item exists in item master
|
Scrap
|
Scrap percent
|
Occurrence
|
If item repeats in BOM
|
RefNum
|
User controlled text field
|
Row
|
System Value
|
ParentRow
|
System Value
|
ParentItem
|
User controlled text field
|
Userdefined
|
User controlled text field
|
Userdefined
|
User controlled text field
|
Userdefined
|
User controlled text field
|
Userdefined
|
User controlled text field
|
Userdefined
|
User controlled text field
|
Userdefined
|
User controlled text field
|
